Product Description
Stainless steel Self-clinching threaded studs, with UNF thread, for stainless steel and metallic materials, Finish passivated.
Product Specs
- SKU:
- 300203003
- Code:
- FHP-032-16
- Thread size (d1):
- 10-32
- Hole size +0,003/0:
- 0,189in
- a min.:
- 0,281in
- d2 ±0,015:
- 0,256in
- h ±0,001:
- 0,01in
- r1 max.:
- 0,003in
- r2 max.:
- 0,005in
- Sheet thickness (s):
- 0,04-0,095in
- A +0,003/-0,0 (gross):
- 0,191in
- B ±0,002 (gross):
- 0,235in
- C ±0,002:
- 0,275in
- H max. (Gross):
- 0,1in
- L ±0,015:
- 1in
