    773-112 - Junction Box Wire Connector by WAGO

773-112 - Junction Box Wire Connector by WAGO

18 to 12 AWG Solid, 16 to 12 AWG Stranded, 400 V, Transparent Housing, Green Face, 2-Port, Junction Box Wire Connector
Availability:
Pricing:
Order:
Out Of Stock
Requires a Quote
Product Documents:
Junction Box Wire Connector; Voltage Rating 400 Volt; Wire Size 18 to 12 AWG Solid, 16 to 12 AWG Stranded; Number of Ports 2; Color Transparent (Housing), Green (Face); Temperature Rating 105 Deg C; Standard Package 100 per Box; Approval UL, CSA, ABS; RoHS Compliant; Wiring Type Side Entry; Overall Dimension 0.362 Inch Width x 0.768 Inch Depth x 0.516 Inch Height; Strip Length 0.47 Inch; Conductor Material Copper; Number of Conductor 2; Current Rating 24 Amp

Pushwire Connection of Solid and Rigid Stranded Wire; Save up to 50 Percent in Wiring Time Over Twist-Type Connectors; Transparent Housing for Visual Inspection of Complete Insertion; Color-Coded for Quick Identification; Versions for 10 AWG, High Temp and Hazardous Locations; RoHS Compliant
Temperature Rating
  • 105 Deg C
  • Cable/Wire Size
  • 18 to 12 AWG
  • Number of Ports
  • 2
  • RoHS Compliant
  • RoHS Comliant
  • Color
  • Transparent (Housing), Green (Face)
  • Available Combo Deals
