Product Description
The 1084-6CN090 Heli-Coil insert provides strong, permanent internal threads designed for heavy-duty applications. Constructed from high-quality stainless steel, this tanged and free-running insert offers excellent durability and precise thread alignment. It features a coarse thread design with an M6x1 thread size and a 1.5D length-to-diameter ratio, making it an essential fastening component for reliable thread repair and reinforcement.
Stainless Steel Construction Engineered from durable stainless steel to deliver long-lasting performance and strength.
Tanged Design Features a tanged style to facilitate smooth and precise driving during installation.
Free-Running Insert Designed as a free-running insert type to allow easy, friction-free thread assembly.
Coarse Thread Specification Features an M6x1 coarse thread pitch to accommodate standard metric fastening needs.
Product Specs
- SKU:
- 1084-6CN090
- Thread Size:
- M6x1
- Thread Series:
- Coarse
- Length:
- 9 mm | 0.3543 in
- Tang:
- Tanged
- Material:
- Stainless Steel
- Number of Free Coils:
- 6-3/4
- Length to Diameter Ratio:
- 1.5D
- Coating/Finish:
- None
