Product Description
The 3585-4CN250 is a genuine Heli-Coil tanged screw-locking, coarse thread insert designed to deliver secure and reliable thread reinforcement. Fabricated from premium stainless steel with no finish, this 1/4"-20 1D insert is supplied in bulk to meet heavy-duty industrial fastening needs.
Screw-Locking Design incorporates a resilient locking coil that exerts constant pressure on mating fasteners to resist loosening from vibration and shock.
Stainless Steel Material provides robust durability and structural integrity for demanding application environments.
Tanged Configuration utilizes a traditional tanged style for easy installation with standard tooling.
Coarse Thread Specification features a precise 1/4"-20 UNC thread size tailored for standard hardware compatibility.
Product Specs
- SKU:
- 3585-4CN250
- Thread Size:
- 1/4"-20
- Thread Series:
- UNC
- Length:
- 0.25 in | 6.3500 mm
- Tang:
- Tanged
- Material:
- Stainless Steel
- Number of Free Coils:
- 3-3/8
- Length to Diameter Ratio:
- 1D
- Coating/Finish:
- None
