Product Description
The Heli-Coil 1185-2BN164 is a high-performance tanged free-running wire thread insert designed to deliver strong, reliable internal threads in various parent materials. Built with durable Phosphor Bronze construction, this #8-32 UNC coarse thread insert features a 1D length ratio (0.164 in / 4.1656 mm body length) to ensure dependable joint integrity. Its bulk packaging makes it an ideal choice for efficient, high-volume assembly operations.
Tanged Design includes a traditional driving tang for straightforward, accurate installation using standard tanged insertion tools.
Free-Running Insert Type allows male fasteners to thread smoothly through the coil without added locking torque or resistance.
Phosphor Bronze Material provides excellent durability, wear resistance, and non-magnetic properties for specialized application environments.
Coarse Thread Profile creates dependable, high-strength internal threads in #8-32 UNC sizes to protect against thread stripping.
Product Specs
- SKU:
- 1185-2BN164
- Thread Size:
- #8-32
- Thread Series:
- UNC
- Length:
- 0.164 in | 4.1656 mm
- Tang:
- Tanged
- Material:
- Phosphor Bronze
- Number of Free Coils:
- 3-1/2
- Length to Diameter Ratio:
- 1D
- Coating/Finish:
- None
