Product Description
1.567" x 1.083" x 0.563", 0.31 to 0.35" L Strip, 630 V, 10/15 A, 28 to 12 AWG, Polyamide 66, Operating Tool Actuated, 5-Pole, Male, 1-Conductor, Multi-Connection System Connector, W/Fixing Flange
Multi-Connection System Connector Type Male, 1-Conductor Voltage Rating 320 Volt (CAT III), 630 Volt (CAT II), 300 Volt (UL/CSA) Current Rating 10/15 Amp (UL/CSA) Number of Poles 5 Cable Size 28 to 12 AWG Terminal Type Screw Body Material Polyamide 66 Approval UL 1059, CSA RoHS Compliant Overall Dimension 1.567 Inch Width x 1.083 Inch Depth x 0.563 Inch Height Actuation Type Operating Tool Strip Length 0.31 to 0.35 Inch Pin Spacing 0.197 Inch Clamping Spring Material Chrome Nickel Spring Steel Contact Material Electrolytic Copper Contact Plating Tin Plated Color Gray Number of Potential 5 Number of Connection Point 5 Number of Connection Type 1 Number of Level 1 Fire Load 0.166 MJ Flammability Rating UL 94V-0 Temperature Rating -60 to 100 Deg C Includes Fixing Flange Applicable Standard IEC/EN 60664-1
