Product Description
The SOUTHCO 96-720 is a versatile 96 Series Lift-off Hinge designed for quick and easy door or panel removal without the use of tools. This feature is essential for maintenance or assembly environments where frequent access to internal components is required.
The lift-off design allows the door to be removed by simply opening it and lifting it off the hinge pins. This model is engineered for durability and a clean aesthetic, providing a low-profile mounting solution for a variety of industrial and commercial enclosures.
Quick-Release Functionality: Enables rapid panel removal for unobstructed access, making it ideal for large equipment or tight service spaces.
Corrosion Resistance: The combination of a chrome-plated zinc body and a stainless steel pin provides a high-quality finish with excellent protection against wear.
Streamlined Design: Features countersunk mounting holes for a flush, professional appearance on the exterior of the enclosure.
Versatile Orientation: Can be installed for left-hand or right-hand door swings depending on the mounting orientation.
Common Uses: Extensively used in telecommunications cabinets, industrial machinery, marine compartments, and medical equipment housings.
Product Specs
- SKU:
- 96-720
- Manufacturer:
- Southco
- Part Number:
- 96-720
- Product Series:
- 96 Series - Lift-Off Hinges
- Hinge Configuration:
- Offset
- Material:
- Zinc Alloy
- Finish:
- Chrome Plated, Bright
- Mounting Style:
- Front Mount / Countersunk Holes
- Hinge Pin Material:
- Stainless Steel
- Rotation Angle:
- 270°
- Radial Load (Max):
- 1000 N (225 lbf)
- Axial Load (Max):
- 1750 N (390 lbf)
