Product Description
1/8" x 0.4" Shank, 0.22" x 0.031" Countersunk Head, 0.188 to 0.25" Grip Range, Stainless Steel, Non-Structural Blind Break Stem, Rivet
Rivet Type Non-Structural Blind Break Stem Shank Diameter 1/8 Inch Mandrel Diameter 0.076 Inch Shank Length 0.4 Inch Head Type Countersunk Head Diameter 0.22 Inch Head Thickness 0.031 Inch Recommended Hole Diameter 0.129 to 0.133 Inch Material Stainless Steel Material Specification IFI 114 Grade 11 Finish Natural Grip Range 0.188 to 0.25 Inch Shear Strength 420 Pound-Force Tensile Strength 530 Pound-Force
Product Specs
- SKU:
- CCCS-04-04
- Color:
- Natural
- Diameter:
- 0.22 in.
- Grip Range:
- 0.188 to 0.25 in.
- Length:
- 0.4 in. Shank
- Material:
- Stainless Steel
- Shape:
- Countersunk Head
- Thickness:
- 0.031 in. Head
- Type:
- Non-Structural Blind Break Stem
