Product Description
35 kV, 4 AWG, 1/4" Stud, 1.35" L, Gray, Electro Tin Plated Copper, Standard with Window, Straight, 1-Hole, Compression Cable Lug
Compression Cable Lug Voltage Rating 35 Kilovolt Conductor Material Copper Conductor Size 4 AWG (Flex Class B/C/G/H/I/K/M), 5, 4, 3 AWG (Flex Diesel Locomotive) Barrel Type Standard with Window, Straight Barrel Length 0.53 Inch Pad Size 0.55 Inch Width x 0.09 Inch Thickness Number of Pad Holes 1 Stud Size 1/4 Inch Color Gray Die Index P29, 8 (Burndy), 29 (T and B) Material Electro Tin Plated Copper Overall Length 1.35 Inch Approval UL 486A/B, CSA C22.2 RoHS Compliant Wire Strip Length 5/8 Inch Temperature Rating 90 Deg C Includes Inspection Window
Product Specs
- SKU:
- LCAX4-14-L
- Color:
- Gray
- Finish:
- Electro Tin Plated
- Length:
- 1.350 in.
- Material:
- Copper
- RoHS Compliant:
- yes
- Type:
- Standard with Window, Straight Barrel
- Voltage Rating:
- 35 Kilovolt
