Product Description
0.94" x 0.31" x 0.03", 22 to 18 AWG, #10 Stud, Red, Vinyl Insulated, Funnel Entry, Standard, Ring Terminal
Ring Terminal Type Funnel Entry, Standard Minimum Conductor Size 22 AWG Maximum Conductor Size 18 AWG Color Red Insulation Type Vinyl Insulated Stud Size #10 Temperature Rating 221 Deg F Standard Package 100 Approval UL 486A/B, UL (Canada and US), CSA C22.2 RoHS Compliant Barrel Type Brazed Seam Voltage Rating 600 Volt Overall Dimension 0.94 Inch Length x 0.31 Inch Width x 0.03 Inch Thickness Insulation Diameter 0.15 Inch Wire Strip Length 5/16 Inch Material Electro Tin Plated Copper Flammability Rating UL 94V-0
Product Specs
- SKU:
- PV18-10R-CY
- Color:
- Red
- Conductor Size:
- 22-18 AWG
- Finish:
- Electro Tin Plated
- Length:
- 0.940 in.
- Material:
- Copper
- RoHS Compliant:
- yes
- Type:
- Funnel Entry
- Width:
- 0.310 in.
