Product Description
M2.5 x 0.45 MM, 3.2 to 3.7 MM OD, 2.5 MM L, Gray, Dry Film Lubricant, 304 Stainless Steel, 3-3/8-Coils, Diamond Knurled, Screw-Locking, Screw Threaded Insert
Screw Threaded Insert Type Diamond Knurled, Screw-Locking Nominal Diameter M2.5 Pitch 0.45 Millimeter External Thread Size 3.2 to 3.7 Millimeter Drill Size 2.65 Millimeter Overall Length 2.5 Millimeter Material AS7245 304 Stainless Steel Finish Dry Film Lubricant Tensile Strength 200000 to 250000 PSI Application Plastic Diameter 1 Number of Coils 3-3/8 Locking Torque 0.22 Millimeter Countersink 2.9 to 3.4 Millimeter Color Gray Applicable Standard MA1565, MA3329/3330/3331, NAS0276, ASME B18.29.2M-2005
Product Videos
Custom Field
Grip Range 1
Inner Diameter (I.D.) 3.2 to 3.7 mm.
Length 2.5 mm.
Material Dry Film Lubricant
Pitch 3.2 to 3.7 mm.
RoHS Compliant Gray
Shape M2.5 x 0.45 mm.
Type Diamond Knurled, Screw-Locking
