Product Description
#8-32 TPI, 0.25 to 0.22" OD, 0.328" L, Gray, Dry Film Lubricant, 304 Stainless Steel, 8-3/8-Coils, Diamond Knurled, Screw-Locking, Screw Threaded Insert (Strip Feed) T3585-2CW328S
Screw Threaded Insert Type Diamond Knurled, Screw-Locking Nominal Diameter #8 TPI 32 Thread Series UNC-2A External Thread Size 0.25 to 0.22 Inch Drill Size #16 Overall Length 0.328 Inch Material AS7245 304 Stainless Steel Finish Dry Film Lubricant Tensile Strength 200000 to 250000 PSI Application Plastic Diameter 2 Number of Coils 8-3/8 Locking Torque 9 Inch-Pound Countersink 0.2 to 0.23 Inch Color Gray Applicable Standard NASM21209, NASM8846, NAS1130, ASME B18.29.1 Packaging Type Strip Feed
Product Videos
Custom Field
Grip Range 2
Inner Diameter (I.D.) 0.25 to 0.22 in.
Length 0.328 in.
Material Dry Film Lubricant
Pitch 0.25 to 0.22 in.
RoHS Compliant Gray
Thread #8-32 TPI
Type Diamond Knurled, Screw-Locking
