Product Description
The Heli-Coil T1084-5E075 is an advanced Tangless® free-running wire thread insert designed to generate high-strength internal threads while eliminating assembly line debris. Precision-formed from high-performance Nitronic 60 stainless steel wire with a diamond cross-section, this insert provides superior anti-galling protection and galling resistance without the need for additional plating or dry lubricants. Featuring an innovative tangless design, it completely removes the need for tang break-off and retrieval, delivering absolute FOD mitigation for cleanroom, vacuum, and high-purity applications. The streamlined free-running configuration allows metric bolts to thread freely until final clamp load is applied, distributing joint stresses evenly across parent materials.
Tangless Architecture Eliminates the physical driving tang to streamline manufacturing efficiency and optimize installation without requiring tang removal tools.
Nitronic 60 Anti-Galling Alloy High-manganese austenitic stainless steel wire prevents friction-induced thread galling and cold welding during high-speed assembly.
Zero FOD GenerationPrevents loose metallic debris from entering sensitive components or internal cavities, making it ideal for aerospace and vacuum environments.
Free-Running Helical Motion Permits standard male metric fasteners to spin smoothly through the insert without added rotational drag or prevailing torque.
Product Specs
- SKU:
- T1084-5E075
- Thread Size (Inch):
- 0.1969
- Thread:
- M5x0.8 Metric Coarse
- Overall Insert Length (Decimal Inch):
- 0.2953
- Tang:
- Tangless
- Material:
- Nitronic 60 Stainless Steel
- Number of Free Coils:
- 6-7/8
- Length to Diameter Ratio:
- 1.5:1 (1.5D Nominal Length)
- Coating/Finish:
- None (Plain)
