Product Description
16 to 14 AWG, 0.25" x 0.032" Tab, Blue, Vinyl Barrel Insulated, Funnel Entry, Female Disconnect
Female Disconnect Type Funnel Entry Tab Size 0.25 Inch x 0.032 Inch Minimum Conductor Size 16 AWG Maximum Conductor Size 14 AWG Color Blue Insulation Type Vinyl Barrel Insulated Temperature Rating 221 Deg F Standard Package 100 Approval UL 310, CSA C22.2 RoHS Compliant Barrel Type Butted Seam Voltage Rating 600 Volt Overall Dimension 0.81 Inch Length x 0.29 Inch Width Insulation Diameter 0.17 Inch Material Tin Plated Brass Wire Strip Length 9/32 Inch Flammability Rating UL 94V-0
Product Videos
Custom Field
Color Blue
Conductor Size 14 AWG
Finish Tin Plated
Length 0.810 in.
Material Brass
RoHS Compliant yes
Type Funnel Entry, Butted Seam Barrel
Width 0.290 in.
Spec Sheet Specification Sheet
