Product Description
16 to 14 AWG, 0.25" x 0.032" Tab, Blue, Vinyl Insulated, Piggyback Disconnect
Piggyback Disconnect Minimum Conductor Size 16 AWG Maximum Conductor Size 14 AWG Insulation Type Vinyl Insulated Color Blue Tab Size 0.25 Inch x 0.032 Inch Maximum Insulation Diameter 0.16 Inch Temperature Rating 194 Deg F Standard Package 50 RoHS Compliant Voltage Rating 300 Volt Overall Dimension 0.88 Inch Length x 0.29 Inch Width Wire Strip Length 9/32 Inch Material Tin Plated Brass Flammability Rating UL 94V-2/HB
Product Specs
- SKU:
- DV14-250P-L
- Color:
- Blue
- Conductor Size:
- 16-14 AWG
- Finish:
- Tin Plated
- Length:
- 0.880 in.
- Material:
- Brass
- RoHS Compliant:
- yes
- Width:
- 0.290 in.
