CFN-M3-1ZI - Nuts for Sheet Metal by PennEngineering ® (PEM ® )

These self-clinching miniature nuts are engineered to provide high-strength, permanent internal threads within ultra-thin metal panels. Featuring a compact, space-saving profile, they install cleanly into the hosting panel, making them ideal for designs with strict space or weight constraints. When pressed into a properly sized round hole, the panel material cold-flows directly into the knurled clinching ring, locking the fastener permanently against push-out and torque-out forces. The zinc plating with a clear chromate finish ensures dependable corrosion resistance while maintaining a clean, flush finish on the back of the hosting sheet.

Miniature Configuration: Compact, space-saving design optimized for close-to-edge installation and tight component spacing in thin sheets.

Flush-Finish Installation: Sits completely flush on the reverse side of the metal panel, preserving a smooth, unmarred surface.

High Torque Resistance: The knurled clinching ring uses cold-flow technology to lock tightly into the panel material for high resistance to rotational forces.

Corrosion Protection: Coated with clear zinc plating to safeguard the carbon steel body from oxidation and premature wear.
