Product Description
6 AWG to 250 KCMIL, 3/8" Stud, Tin Plated Extruded Aluminum Alloy, 2-Conductor, 1-Pad Hole, Double Barrel, Mechanical Connector Lug
Mechanical Connector Lug Type Double Barrel Number of Conductors 2 Minimum Conductor Size 6 AWG Maximum Conductor Size 250 KCMIL Conductor Material Aluminum/Copper Screw Type 3/8 Inch Hex Head Material Tin Plated Extruded Aluminum Alloy Number of Pad Holes 1 Pad Size 1.56 Inch Length x 1.5 Inch Width x 0.25 Inch Thickness Stud Size 3/8 Inch Overall Length 2.56 Inch Approval UL (Canada and US), CSA RoHS Compliant Color Metallic Application Stranded Aluminum or Copper Code Conductor
Product Videos
Custom Field
Color Metallic
Finish Tin Plated
Height 1.190 in.
Length 2.560 in.
Material Extruded Aluminum Alloy
RoHS Compliant yes
Type Double Barrel
Width 1.640 in.
